ACL 2位3通直动式阀Direct Acting 312

ACL 2位3通直动式阀Direct Acting 371

说明

电磁阀3通不锈钢AISI 316

直接作用提升阀型

建造

阀体AISI 316

电枢管AISI 316

柱塞和芯AISI 430FR

遮光环银色

弹簧AISI 316

密封NBR-FPM-EPDM

功能

最大允许压力PS 50barD

最大流体粘度25cSt ( mm2/s )

环境温度:根据线圈,从-10°C到+80°C

通用安装位置

DESCRIPTION

Solenoid valve 3 way in stainless steel AISI 316

direct acting poppet type

COSTRUCTION

Body AISI 316

Armature tube AISI 316

Plunger and core AISI 430FR

Shading ring Silver

Spring AISI 316

Seal NBR - FPM- EPDM

FEATURES

Maximum allowable pressure PS 50barD

Maximum fluid viscosity 25cSt (mm2/s)

Ambient temperature. from -10°C to +80°C according to the coil

Universal mounting position

3/2 Direct Acting NO

TYPE

PORT SIZE

ORIFICE

Kv

DIFFERENTIAL PRESSURE ΔP bar

NOMINAL POWER

COIL

SEAL

TEMPERATURE RANGE

mm

m3/h

MIN

MAX

AC-VA

DC

width

TYPE

1-2

2-3

AC

DC

INRUSH

HOLDING

W

°C

371 NO

1/8

1.5

1.5

0.06

0

15 10 6

15 10 6

12

8

6.5

22

3

NBR EPDM FPM

-10 +90 -10 +140 -10 +140
