电子浓度计的使用方法

电子浓度计的使用方法

1.AU-300C测量范围: 0.1~100.0%， 浓度解析度: 0.1%， 密度精度0.001 g/cm3

2.AU-120C测量范围: 0.01~100.00%， 浓度解析度: 0.01%， 密度精度0.0001 g/cm3

电子浓度计使用方法

1、机器在0.000的待测模式下

2、在烧杯内注入待测样品至50刻度线处，然后放于测量架正中央的下方，将挂钩挂在测量架中央，“J"形 末端部位

没在待测样品中，按[ZERO] 键归零。

3、将标准砝码挂于挂钩的"J"形末端上，挂到测量架中央，(标准 砝码需完全浸没在待测样品中)待稳定符号“o”显

按[ENTER] 键，屏幕上的箭头指向SG此时即为密度值。

4、取下标准砝码，清洗并擦拭后，在使用本砝码的前提下，按上述2至3的步骤，可循环测量其它样品的密度。

Usage of electronic concentration meter

1. AU-300C measurement range: 0.1~100.0%, concentration resolution: 0.1%, density accuracy: 0.001 g/cm3

2. AU-120C measurement range: 0.01~100.00%, concentration resolution: 0.01%, density accuracy 0.0001 g/cm3

Use method of electronic concentration meter

1. The machine is in 0.000 pending mode

2. Inject the sample to be measured into the beaker to the mark of 50, and then place it under the center of the measuring frame. Hang the hook at the center of the measuring frame and the "J" shaped end

If it is not in the sample to be tested, press the [ZERO] key to return to zero.

3. Hang the standard weight on the "J" end of the hook, hang it in the center of the measuring frame, (the standard weight needs to be completely immersed in the sample to be measured), and the symbol "o" to be stabilized is displayed

Press the [ENTER] key, the arrow on the screen points to SG, which is the density value.

4. After removing the standard weight, cleaning and wiping, the density of other samples can be measured circularly according to the steps of 2 to 3 above on the premise of using this weight.
