CCS压力开关6900GE系列
CCS 压力开关 6900G,6901G,690GZ,6900P,6901P系列6900G6901G带端子接口尺寸1/4"接口材料铝合金隔膜材料聚丁钠橡胶接口尺寸1/4"接口材料铝合金隔膜材料聚丁钠橡胶最大允许压力(KG)设定压力范围(KG)压力开关型号SPDTDPDTSPDTDPDT34.480.21～1.246900G126900GM126901G126901GM1234.
详细介绍
CCS 压力开关 6900G,6901G,690GZ,6900P,6901P系列
| 6900G | 6901G带端子 | ||||||||||||
|
|
最大允许压力(KG) | 设定压力范围(KG) | 压力开关型号 | |||
SPDT | DPDT | SPDT | DPDT | ||
34.48 | 0.21～1.24 | 6900G12 | 6900GM12 | 6901G12 | 6901GM12 |
34.48 | 0.41～4.90 | 6900G14 | 6900GM14 | 6901G14 | 6901GM14 |
103.45 | 0.83～9.79 | 6900G16 | 6900GM16 | 6901G16 | 6901GM16 |
103.45 | 2.07～24.48 | 6900G18 | 6900GM18 | 6901G18 | 6901GM18 |
137.93 | 20.69～65.17 | 6900G20 | 6900GM20 | 6901G20 | 6901GM20 |
206.90 | 48.28～165.52 | 6900G22 | 6900GM22 | 6901G22 | 6901GM22 |
| 6900GZ | 6901GZ | ||||||||||||
|
|
最大允许压力(KG) | 设定压力范围(KG) | 压力开关型号 | |||
SPDT | DPDT | SPDT | DPDT | ||
34.48 | 0.21～1.24 | 6900GZ12 | 6900GMZ12 | 6901GZ12 | 6901GMZ12 |
34.48 | 0.62～4.76 | 6900GZ14 | 6900GMZ14 | 6901GZ14 | 6901GMZ14 |
103.45 | 1.24～9.52 | 6900GZ16 | 6900GMZ16 | 6901GZ16 | 6901GMZ16 |
103.45 | 3.10～23.79 | 6900GZ18 | 6900GMZ18 | 6901GZ18 | 6901GMZ18 |
137.93 | 20.69～63.79 | 6900GZ20 | 6900GMZ20 | 6901GZ20 | 6901GMZ20 |
206.90 | 48.28～160.00 | 6900GZ22 | 6900GMZ22 | 6901GZ22 | 6901GMZ22 |
| 6900P | 6901P | ||||||||||||
|
|
最大允许压力(KG) | 设定压力范围(KG) | 压力开关型号 | |||
SPDT | DPDT | SPDT | DPDT | ||
137.93 | 1.03～13.10 | 6900P32 | 6900PM32 | 6901P32 | 6901PM32 |
206.90 | 10.34～102.76 | 6900P34 | 6900PM34 | 6901P34 | 6901PM34 |
344.83 | 34.48～208.97 | 6900P36 | 6900PM36 | 6901P36 | 6901PM36 |
689.66 | 137.93～413.79 | 6900P38 | 6900PM38 | 6901P38 | 6901PM38 |
接点容量
|  | |||||||||||||||||||
SERIES:
- 6900G*
- 6900GZ*
ADJUSTABLE SET POINT RANGE:
- 1 to 3400 PSIG
- 0.07 to 234 bar
- 6.89 to 23400 kPa
OPERATING TEMPERATURE:
Temperature limits change with O-ring selection.
- -40° to 186°F
- -40° to 86°C
